Bobcat CT5550
Bobcat CT5545 Key Features
3FT-TH4-U Engine Model
50 Horsepower
Infinite, 3 Range Hydrostatic Transmission
Wet Multi Disc Brake
3,177 lb Lift Capacity
Bobcat CT5545 Specs
Key Specifications
| Horsepower | 50 hp |
| Lift Capacity at 24″ behind Lift Point | 3,177 lb |
| PTO Horsepower (PTO HP) | 38.9 hp |
| Transmission Type | Infinite, 3 Range Hydrostatic (Servo control valve with Electric solenoid) |
| Width | 74.2 in |
| Turning Radius | 9′ 9″ |
| Wheelbase | 6′ 3″ |
Engine
| Emissions Tier (EPA) | Tier 4 |
| Horsepower | 50 hp |
| Displacement | 111 in³ |
| Number of Cylinders | 3 |
| Gross HP | 50 hp |
| Engine Model | 3FT-TH4-U |
Performance
| Operating Weight | 4,685 lb |
| Travel Speed | 17.5 mph |
| Travel Speed – Reverse | 17.5 mph |
| 3-Point Hitch | Category 1 |
| 3-Point Lift Control Type | Position with Draft Control |
| Lift Capacity at 24″ behind Lift Point | 3,177 lb |
| Rear PTO System | Independent |
| Rear PTO – RPM | 540 RPM |
| PTO Horsepower (PTO HP) | 38.9 hp |
| Mid PTO – RPM | 2,103 RPM |
Capacities
| Fuel Tank | 14.8 gal |
Hydraulic System
| Implement Hydraulic Flow | 9.6 gal/min |
| Total Hydraulic Flow | 17.8 gal/min |
| Steering Hydraulic Flow | 8.2 gal/min |
Drive System
| Brake Type | Wet Multi Disc |
| Transmission Type | Infinite, 3 Range Hydrostatic (Servo control valve with Electric sol.) |
Dimension
| Length | 139.6 in |
| Width | 74.2 in |
| Height | 94.2 in |
| Ground Clearance | 13 in |
| Turning Radius | 9′ 9″ |
| Wheelbase | 6′ 3″ |
| Front Tire Size | Front Industrial (AG, Turf) 10-16.5 (8-16, 29X12.5-15) |
| Rear Tire Size | Rear Industrial (AG, Turf) 17.5-24 (13.6-24, 44X18-20) |
Loader Attachment
| Loader Lift Height | 9′ 1″ |
| Lift Capacity at Bucket Pivot | 2,346 lb |
| Bucket Width | 6′ 0″ |
FAQs
What is the horsepower of the Bobcat CT5550?
The Bobcat CT5550 is a 50-horsepower.
What is the lift capacity of the Bobcat CT5550 tractor?
The Bobcat CT5550 front-end loader has a lift capacity of approximately 3,177 lbs.
How much does a Bobcat CT5550 weigh?
The Bobcat CT5550 has an operating weight of 4,685 lbs.
What is the travel speed of the Bobcat CT5550 ?
The Bobcat CT5550 travel speed Forward is 17.5 mph, and Reverse Speed is 17.5 mph
What attachments are compatible?
Bobcat CT5550 Popular attachments include a Front-end loader, Tiller, Finish mower, Backhoe , Angle blade, Mid-mount mower
What warranty is offered?
The Bobcat CT5550 warranty offers 24 months of coverage for defects in materials and workmanship or 1,500 hours of use, whichever comes first.
What is the fuel tank capacity of Bobcat CT5550?
The CT5550 has a 14.8-gallon fuel tank.
